Vacuum Pressure Swing Adsorption (VPSA) oxygen generation system is designed to efficiently extract high-purity oxygen from ambient air. This technology operates through alternating low-pressure and vacuum adsorption cycles, ensuring stable oxygen purity while significantly reducing energy consumption - making it an ideal solution for large-scale oxygen demand.






Technical Specification
▔▔▔
Title | Unit | Parameters |
Oil Purity | % | 80 ~ 93 |
Oxygen Flow Rate | Nm3/hr | 40 ~ 7500 |
Oxygen Dew Point | °C | -50 ~ -30 |
Oxygen Pressure | MPa | 0.015 ~ 20 |
Operating Pressure | MPa | ±0.05 |
Inlet Air Temperature | ℃ | 20 ~ 35 |
| Power Supply Voltage | V | Customizable |
Product Specification
▔▔▔
Oxygen Output*(Nm3/hr) | Oxygen Purity* (%) | Oxygen Pressure* (MPa) | Installed Power (kW) | Operating Power (kW) | Water Consumption (T/h) | |
Cooling Water | Soft Water | |||||
2000 | 93 | 0.015 | 1000 | 580 | 70 | 2 |
3000 | 93 | 0.015 | 1400 | 870 | 85 | 2.5 |
4500 | 93 | 0.015 | 2000 | 1300 | 100 | 3 |
5500 | 93 | 0.015 | 2500 | 1600 | 120 | 3 |
7500 | 93 | 0.015 | 2500 | 1600 | 120 | 3 |
* All performance parameters are calculated based on standard sea-level conditions.
* Flow rate, purity, pressure, and power supply voltage can be customized as required.
